51
{Single, Dual, Quad} Sundtek SkyTV Ultimate / Re: Konfiguration SkyTV Ultimate 6 2016/Q1, sundtek_netinst.sh
« Letzter Beitrag von tobias am September 08, 2024, 09:02:44 Vormittag »
Hallo zusammen,

es ist nun über ein Jahr her und ich habe immer noch dieselben Probleme...

Ich möchte prinzipiell nur TV im Netzwerk streamen. Ist mein Vorgehen mit net_install und /opt/bin/mediaclient --installstreamer falsch? Gibt es bessere/andere Wege?
52
{Single, Dual, Quad} Sundtek SkyTV Ultimate / Re: Question regarding dvbs2x
« Letzter Beitrag von Dima73 am September 05, 2024, 07:00:32 Vormittag »
Zitat
USB 3.0 FBC tuner
Do you have any test samples yet?
I would buy one :).
53
{Single, Dual, Quad} Sundtek SkyTV Ultimate / Re: Question regarding dvbs2x
« Letzter Beitrag von Sundtek am September 05, 2024, 02:28:00 Vormittag »
Hi,

you will need either a splitter with a DC blocker (for Unicable) or a second LNB cable to the LNB.
We have a USB 3.0 FBC tuner in the pipeline however it's without S2X at the beginning. We are currently changing our hardware platform to make it more modular / flexible and easier to upgrade.
54
{Single, Dual, Quad} Sundtek SkyTV Ultimate / Question regarding dvbs2x
« Letzter Beitrag von orahmed am September 04, 2024, 02:23:00 Nachmittag »
Hello everyone I have a quick question regarding the dvbs2x SkyTV Dual 2x card Are the two tuners linked internally or do I have to use a splitter to power the tuners? Another question is can we have an FCB tuner in the next version thank you
55
{Single, Dual, Quad} Sundtek SkyTV Ultimate / Re: Problem sundtek dvb-s2 x tvheadend multistream 5w
« Letzter Beitrag von orahmed am August 28, 2024, 03:41:58 Nachmittag »
Hi I did a driver update Now it works very well with tvheadend Thank you for your help
56
{Single, Dual, Quad} Sundtek SkyTV Ultimate / Re: Problem sundtek dvb-s2 x tvheadend multistream 5w
« Letzter Beitrag von orahmed am August 28, 2024, 11:38:57 Vormittag »
Hi I just saw your answer I was on vacation Thank you for your response I will test and see the result
57
Sundtek DAB/DAB+/FM/FM HD / Re: Sundtek DAB/DAB+/FM/FM HD Howto
« Letzter Beitrag von Sundtek am August 28, 2024, 03:06:57 Vormittag »
Sorry hatte das hier nicht gesehen, werden das auf LibreElec testen.
58
{Single, Dual, Quad} Sundtek SkyTV Ultimate / Re: adapter0 macht Probleme - viele Programme werden nicht gefunden
« Letzter Beitrag von Sundtek am August 25, 2024, 12:44:27 Nachmittag »
Hallo,

wir haben das überprüft, anscheinend gab's bei der letzten Chip Charge die wir erhalten haben Probleme. Wir haben Dir einen anderen Tuner zugeschickt.
Leider kamen da einige Tuner durch's Testen da diese anders getestet werden müssen.
Betroffene Tuner müssen dann zurück und bekommen nen neuen Receiver Chip.
59
{Single, Dual, Quad} Sundtek SkyTV Ultimate / adapter0 macht Probleme - viele Programme werden nicht gefunden
« Letzter Beitrag von ToKo am August 22, 2024, 12:59:43 Nachmittag »
Hallo,

ich betreibe einen Duo Ultimate unter Ubuntu Server 24.04 mit TvHeadEnd.
Der Adapter0 macht Probleme.

Der LNB wurde schon ausgetauscht: keine Änderung.
Ein Tauschen der beiden SAT Kabel zw. adapter0 und adapter1: keine Änderung.

Der Tuner war beim Tausch der SAT-Kabel strom- und usb-los.
Adapter0 macht weiter diesselben Probleme.

Die LED leuchtet blau.

In TvHeadEnd findet man zur Hälfte als Scan Result "fail". Es wurden nur 110 Muxe und 330 Services gefunden.
Mit einer DVBSky S960 USB Box gibt es keine Probleme mit der SAT-Anlage und den beiden genannten SAT-Kabeln (130 Muxe und 1846 Services).
Ein Sony TV funktioniert ebenfalls mit der SAT Anlage und findet alle Sender.
Ich schliesse daher einen Fehler im Bereich SAT-Kabel, LNB oder Ausrichtung der Schüssel aus.

Liegt ein Defekt vor oder ein Fehler in der Konfiguration?
Was kann ich tun?

Gruss,
Thomas

Code: [Auswählen]
/opt/bin/mediaclient --readsignal=10 -d /dev/dvb/adapter0/frontend0 --band UNIVERSAL
== reading digital TV signal ==
SIGNAL: [                                 ] (  0%) SATQUALITY:  28%  SNR:   0  BER:   6174 FREQ: 11362000   Hz LOCKED:  NO SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 90%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 90%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 90%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 90%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 90%) SATQUALITY:  88%  SNR:  16  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 90%) SATQUALITY:  88%  SNR:  16  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  88%  SNR:  16  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  88%  SNR:  16  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF



/opt/bin/mediaclient --readsignal=10 -d /dev/dvb/adapter1/frontend0 --band UNIVERSAL
== reading digital TV signal ==
SIGNAL: [                                 ] (  0%) SATQUALITY:  29%  SNR:   0  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  88%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  86%  SNR:  16  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  86%  SNR:  15  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF
SIGNAL: [..............................   ] ( 91%) SATQUALITY:  88%  SNR:  16  BER:      0 FREQ: 11362000   Hz LOCKED: YES SYS: DVB-S2 SYM: 22000000 FEC: FEC_2_3 MOD: PSK_8 VOLTAGE: H(18V) TONE: OFF




/opt/bin/mediaclient --testastra -d /dev/dvb/adapter0/frontend0
Testing Astra 19.2 Frequencies
DVBS
LO Band / 18V:
Checking for lock:
..........
LO Band / 13V:
Checking for lock:
..........
HI Band / 18V:
Checking for lock:
. [LOCKED]
HI Band / 13V:
Checking for lock:
..........
DVB-S2 ZDF HD / 18V
Checking for lock:
. [LOCKED]



/opt/bin/mediaclient --testastra -d /dev/dvb/adapter1/frontend0
Testing Astra 19.2 Frequencies
DVBS
LO Band / 18V:
Checking for lock:
..........
LO Band / 13V:
Checking for lock:
. [LOCKED]
HI Band / 18V:
Checking for lock:
. [LOCKED]
HI Band / 13V:
Checking for lock:
. [LOCKED]
DVB-S2 ZDF HD / 18V
Checking for lock:
. [LOCKED]



/opt/bin/mediaclient -e
**** List of Media Hardware Devices ****
device 0: [             Dual S2]  DVB-S/S2, REMOTE-CONTROL, DVB-S/S2
  [INFO]:
     STATUS: ACTIVE
  [BUS]:
     ID: 1-2
  [SERIAL]:
     ID: U240620214222
  [DVB-S/S2]:
     FESTATUS: ACTIVE
     LNBVOLTAGE: ENABLED
     LNBSUPPLY: USBPOWER
     LNBSTATUS: OK
     FRONTEND: /dev/dvb/adapter0/frontend0
     DVR: /dev/dvb/adapter0/dvr0
     DMX: /dev/dvb/adapter0/demux0
  [REMOTECONTROL]:
     INPUT0: /dev/mediainput0
  [DVB-S/S2]:
     FESTATUS: ACTIVE
     FRONTEND: /dev/dvb/adapter1/frontend0
     DVR: /dev/dvb/adapter1/dvr0
     DMX: /dev/dvb/adapter1/demux0




/opt/bin/mediaclient --lc
**** List of Media Clients ****
/dev/dvb/adapter0/frontend0:
  No client connected
/dev/dvb/adapter0/dvr0:
  No client connected
/dev/dvb/adapter0/demux0:
  No client connected
/dev/mediainput0:
  No client connected
/dev/dvb/adapter1/frontend0:
  No client connected
/dev/dvb/adapter1/dvr0:
  No client connected
/dev/dvb/adapter1/demux0:
  No client connected


cd /opt/bin
./mediaclient --shutdown
Shutting down Multimedia Stack
./mediasrv -v


2024-08-22 13:01:55 [3033] UID: 0 SUID 0
2024-08-22 13:01:55 [3033] Alsa Blocking on (default)
2024-08-22 13:01:55 [3033] Starting up Multimedia Framework (Mar 17 2024 19:46:26)
2024-08-22 13:01:55 [3033] Semaphore exists, removing and reallocating it
2024-08-22 13:01:55 [3033] Detected DVB version.h
2024-08-22 13:01:55 [3034] Starting service processor (PID 3034)
2024-08-22 13:01:55 [3033] API Version: 5.12
2024-08-22 13:01:55 [3033] Running on Linux (6.8.0-41-generic)
2024-08-22 13:01:55 [3033] Detected: AuthenticAMD
2024-08-22 13:01:55 [3033] This CPU supports: MMX, SSE, SSE2
2024-08-22 13:01:55 [3033] scanning devices
2024-08-22 13:01:55 [3033]
2024-08-22 13:01:55 [3033] Scanning for drivers
2024-08-22 13:01:55 [3033] found lib: libdrv_em28xx.so
2024-08-22 13:01:55 [3033] found lib: libdrv_fm_dab_dabplus.so
2024-08-22 13:01:55 [3033] found lib: libdrv_fm.so
2024-08-22 13:01:55 [3033] found lib: libdrv_tntdvb.so
2024-08-22 13:01:55 [3033] found lib: libdrv_hikarisoft_isdb.so
2024-08-22 13:01:55 [3033] found lib: libdrv_net.so
2024-08-22 13:01:55 [3033] found lib: libdrv_vivi.so
2024-08-22 13:01:55 [3033] found lib: libdrv_eLight.so
2024-08-22 13:01:55 [3033] found lib: libdrv_ngTV.so
2024-08-22 13:01:55 [3033]
2024-08-22 13:01:55 [3033] Scanning for plugins
2024-08-22 13:01:55 [3033] found lib: libencoder_plugin.so
2024-08-22 13:01:55 [3033] MediaAVPlugin: MPEG Encoder
2024-08-22 13:01:55 [3033] Copyright: (C) Tpe 2011/2012
2024-08-22 13:01:55 [3033]
2024-08-22 13:01:55 [3033] Starting up device manager
2024-08-22 13:01:55 [3033] scanning devices done
2024-08-22 13:01:55 [3033] attached devices:
2024-08-22 13:01:55 [3034] Autostarting scripts in /etc/sundtek/
2024-08-22 13:01:55 [3034] executed all available items
2024-08-22 13:01:55 [3033] registering ID: 0
2024-08-22 13:01:55 [3033] Infrared Control Support is disabled in configuration file
2024-08-22 13:01:55 [3033] Memory mapped transfers are not available
2024-08-22 13:01:55 [3033] Board config found: Sundtek SkyTV Dual 8 (eLight)
2024-08-22 13:01:55 [3033] This board provides 2 frontends
2024-08-22 13:01:55 [3033]
2024-08-22 13:01:55 [3033] *********
2024-08-22 13:01:55 [3033] Signature: Sundtek
2024-08-22 13:01:55 [3033] Initializing SYSV-IPC
2024-08-22 13:01:55 [3033] Allocation using pg for type 65678
2024-08-22 13:01:55 [3033] Allocated Shared memory buffer: 0x7991a586a000
2024-08-22 13:01:57 [3033] demodulator successfully attached (DVB_S/S2)!
2024-08-22 13:01:57 [3033] attaching second tuner...
2024-08-22 13:01:57 [3033] Allocation using pg for type 65678
2024-08-22 13:01:57 [3033] Allocated Shared memory buffer: 0x7991a526a000
2024-08-22 13:01:58 [3033] demodulator successfully attached (DVB_S/S2)!
2024-08-22 13:01:58 [3033] Configuring Dual LNB Power Supply
2024-08-22 13:01:58 [3033] Vertical Polarisation is set to 14.00 Volt
2024-08-22 13:01:58 [3033] Horizontal Polarisation is set to 19.10 Volt
2024-08-22 13:01:58 [3033] Enabling LNB status monitor
2024-08-22 13:01:58 [3033] Using Sundtek remote control layout
2024-08-22 13:01:58 [3033]
2024-08-22 13:01:58 [3033] IR Setup
.... ir disabled
2024-08-22 13:01:58 [3033] registered virtual: /dev/mediainput0
2024-08-22 13:01:58 [3033] registering: adapter0/0
2024-08-22 13:01:58 [3033] registered virtual: /dev/dvb/adapter0/frontend0
2024-08-22 13:01:58 [3033] registered virtual: /dev/dvb/adapter0/demux0
2024-08-22 13:01:58 [3033] registered virtual: /dev/dvb/adapter0/dvr0
2024-08-22 13:01:58 [3033] registering: adapter1/0
2024-08-22 13:01:58 [3033] registered virtual: /dev/dvb/adapter1/frontend0
2024-08-22 13:01:58 [3033] registered virtual: /dev/dvb/adapter1/demux0
2024-08-22 13:01:58 [3033] registered virtual: /dev/dvb/adapter1/dvr0
2024-08-22 13:01:58 [3033] Driver loaded within 3188 milliseconds
2024-08-22 13:02:02 [3033] Initial devicescan done, switching detection mode
2024-08-22 13:02:13 [3033] [FE0] . o ( Enabling Standby ) o .
2024-08-22 13:02:13 [3033] [FE0] Set Voltage off
2024-08-22 13:02:13 [3033] [FE1] . o ( Enabling Standby ) o .
2024-08-22 13:02:13 [3033] [FE1] Set Voltage off




60
{Single, Dual, Quad} Sundtek SkyTV Ultimate / Re: Problem sundtek dvb-s2 x tvheadend multistream 5w
« Letzter Beitrag von Sundtek am August 21, 2024, 11:00:04 Nachmittag »
I updated the documentation (for testing on the console/Terminal):

https://sundtek.com/wiki/index.php?title=Mediaclient#DVB-S.2FS2.2FS2X_Tuning

and added the corresponding Multistream options.

For the DVB Protocol, only DTV_STREAM_ID is used (it will forward the correct parameter to the driver now). So just about any existing application which supports Multistream will work with it.

To confirm that the correct transponder is tuned you can just run

/opt/bin/mediaclient --tsscan /dev/dvb/adapter0/dvr0

it will scan the transport stream and display the services.

The drivers are updated, just run the netinstaller and it will update the drivers.
